OPW 11APF-40FS 3/4" Automatic Unleaded Nozzle

The OPW 11AF® Nozzle is a sturdy industry-proven standard used primarily for fueling up to 15 gallons per minute. The 11AF® is an automatic dispensing nozzle designed for use in transfer pump. This nozzle should not be used for retail applications, and does not include a No Pressure – No Flow or Interlock Device.

Features

• The new and improved farm hanger is now made from stamped metal and bolted to the nozzle, making it stronger and sturdier than ever
• UL and ULC listed for use in gasoline, diesel, and up to 10% ethanol blends. See specific listings
• New bleeder poppet orifices allow for use in transfer pumps not equipped with air elimination systems
• Prevents consumer from jamming the nozzle in an open position – Blocker on lever guard
• Durable lever guard that won't scratch your customers' vehicles – Made from Duratuff®
• Easy to use – Utilizing Accu-Stop® to-the-penny Flow Control Technology
• Easy to open even at high pressures utilizing Dual Poppets
• Convenient – One-finger hold-open clip that is easy to set the flow rate (not on all models)
• Works with self-priming and non self-priming pumps

Design working pressure

• 50 psi (3.45 bar) maximum pressure
• When bushing from 1" hose on the 1A nozzle, use a 28S Bushing Adaptor

Materials

• Body: Aluminum
• Lever & Lever Guard: Duratuff®
• Packing: Graphite with Teflon®
• Disc: Viton®
• Spouts: Aluminum
• Inlet size: 3/4" NPT
• Weight: 2.85 lbs.
