An increased cabinet size and larger solution tank makes the RS-500 more versatile and productive. By using an octagonal full-opening door, we've increased access to the turntable allowing operators enhanced loading capabilities. Simple operating controls stainless-steel nozzles, a gasket-free door and a large 70-gpm pump, demonstrate Ranger's commitment to enhance performance and productivity. Like all Ranger spray-wash cabinets, the RS-500 is built to last. We purposely constructed the cabinet and door with heavy-duty 12-gauge steel, then we coat it with an industrial two-step primer and polyurethane finish. All-around performance, durability and improved operator convenience helps make the RS-500 the definitive choice among professionals worldwide.
- 50 Gallon Tank
- Large 70-gpm Pump
- Heavy-Duty 12-gauge Steel Door
- 500 Lbs Load Capacity
- 135° - 175° Fahrenheit Water Temperature
- Removable Tank Screen
- Stainless Oil Skimmer
- Removable Parts Tree
- Stainless-Steel Nozzles
- Full Opening Octagonal Door
- 25 Pounds Detergent
| Additional Info | Overall Height - 66" Inside Height - 43" Inside Width - 32" Turntable Diameter - 30" Recommended Floor Space - 44" x 43" Load Capacity - 500 lbs. Cycle Timer - 0-60 minutes Stainless-Steel Nozzles - 18 Cabinet / Door Construction - Steel / 12 Gauge / .109 Thickness Pump Output - 75 psi @ 70 gpm Motor (*) - 1-HP / 220 Volt AC / 60 Hz / 1 Phase Electric Heater - 6 Kilowatts Water Temperature - 135° - 175° Fahrenheit Large Drain Pipe - Standard Heavy-Duty Rubber Casters - Standard Tank Capacity - 50 Gallons Removable Tank Screen - Standard Stainless Oil Skimmer - Standard Friction-Drive Turntable System - Standard Full Opening Octagonal Door - Standard Gasket-Free Door - Standard Small Parts Basket - Standard Steam Vent - Optional Stainless-Steel Handles - Standard Removable Parts Tree - Standard 25 pounds Detergent - Standard The design, material and specifications are subject to change without notice. |
