Our newest line of XPR-Series 2-Post lifts offers a wide selection of durable, safe and reliable systems for virtually every lifting application. Powerful and secure, BendPak's XPR-10 in particular has an incredibly rapid lift speed and a robust menu of features to increase efficiency and productivity, but with fewer serviceable parts and reduced necessary maintenance. The results are lower operating expenses and higher productivity. If you're looking to make more money in less time than ever before, you'll find that the new XPR-10 lift is the perfect addition to your shop.
- 10,000-lb lifting capacity
- Expandable top beam accommodates wide or narrow configurations
- Padded overhead safety shutoff bar
- Single-piece columns
- Drop-end arms provide a lower pad height
- Dual hydraulic direct-drive cylinders
- Oversized 53" tall carriage for superior strength and durability
- Electric / hydraulic power system
- Large, 17" x 19" A36 steel base plate
- Self-lubricating dura-glide UHMW polyethylene bearing system
- Single-point safety release
- Safety locks in each column spaced every 3"
- Automatic arm restraints
- Heavy-duty 1/2" aircraft-quality equalizer cables
- Oversized cable sheave diameter reduces cable fatigue
- 8-piece truck and van adapter set standard
- Triple-telescoping arms
- Versatile drop-in contact pads with stackable adapters
- ETL Approved
| Capacity | 10,000 lbs. |
| Additional Info | Lifting capacity*: 10,000 lbs. / 4,536 kg *Max capacity / front axel: 5,000 lbs. / 2,268 kg *Max capacity / rear axel: 5,000 lbs. / 2,268 kg Overall height: 145" / 3,683 mm Width overall (NARROW CONFIG): 132" / 3,353 mm Width overall (WIDE CONFIG): 145" / 3,683 mm Width outside of columns (NARROW): 127" / 3,226 mm Width outside of columns (WIDE): 140" / 3,556 mm Floor to overhead switch: 141" / 3581 mm Inside columns (NARROW): 102" / 2,791 mm Inside columns (WIDE): 115" / 2,921 mm Front arm min reach: 25-1/2" / 648 mm Front arm max reach: 49-1/2" / 1,257 mm Rear arm min reach: 32-1/2" / 825 mm Rear arm max reach: 52-1/2" / 1,333 mm Min pad height: 4" / 102 mm Rise: 69" / 1,753 mm Lift height max (pad only): 73" / 1,854 mm Lift height max (6" adapter): 79" / 2,007 mm Minimum drive-thru clearance: 93" / 2,362 mm Motor: 220 VAC / 60 Hz / 1 Ph Time to full rise: 45 sec Max load per arm: 2,500 lbs. / 1,134 kg |
