**10,000 lb. 2-Post Clearfloor Lift**
*Narrow Design*
The BendPak XPR-10C offers exceptional direct-drive lifting performance and clearfloor convenience. This super-industrial-strength piece of equipment has got it all: cutting-edge technology, top of the line materials, design that's ahead of its time and a 10,000 pound lifting capacity. Fits in shops with ceilings higher than 12', and it won't crowd your floor while you work beneath a vehicle.
* 10,000-lb. lifting capacity
* Padded overhead safety shutoff bar
* Wide or narrow drive-thru configuration
* Single-piece columns
* Single-point safety release
* Drop-end arms provide a lower pad height
* Dual hydraulic direct-drive cylinders
* Oversized 53" tall carriage for superior strength and durability
* Electric / hydraulic power system
* Large, 17" x 19" A36 steel base plate
* Self-lubricating dura-glide UHMW polyethylene bearing system
* Safety locks in each column spaced every 3"
* Automatic arm restraints
* Heavy-duty 3/8" aircraft-quality equalizer cables
* Oversized cable sheave diameter reduces cable fatigue
* 8-piece truck and van adapter set comes standard
* Triple-telescoping arms provide increased range for lifting point access
* Versatile drop-in contact pads with stackable adapters
*Narrow Design*
The BendPak XPR-10C offers exceptional direct-drive lifting performance and clearfloor convenience. This super-industrial-strength piece of equipment has got it all: cutting-edge technology, top of the line materials, design that's ahead of its time and a 10,000 pound lifting capacity. Fits in shops with ceilings higher than 12', and it won't crowd your floor while you work beneath a vehicle.
* 10,000-lb. lifting capacity
* Padded overhead safety shutoff bar
* Wide or narrow drive-thru configuration
* Single-piece columns
* Single-point safety release
* Drop-end arms provide a lower pad height
* Dual hydraulic direct-drive cylinders
* Oversized 53" tall carriage for superior strength and durability
* Electric / hydraulic power system
* Large, 17" x 19" A36 steel base plate
* Self-lubricating dura-glide UHMW polyethylene bearing system
* Safety locks in each column spaced every 3"
* Automatic arm restraints
* Heavy-duty 3/8" aircraft-quality equalizer cables
* Oversized cable sheave diameter reduces cable fatigue
* 8-piece truck and van adapter set comes standard
* Triple-telescoping arms provide increased range for lifting point access
* Versatile drop-in contact pads with stackable adapters
| Capacity | 10,000 lbs. |
| Additional Info | Lifting capacity*: 10,000 lbs. / 4,536 kg o *Max capacity / front axel: 5,000 lbs. / 2,268 kg o *Max capacity / rear axel: 5,000 lbs. / 2,268 kg Overall height: 145" / 3,683 mm Overall width (outside of base plate): 132" / 3,353 mm Width (outside of columns): 124" / 3,150 mm Floor to overhead switch: 141" / 3,581 mm Inside columns: 102" / 2,591 mm Front arm min reach: 23-1/2” / 597 mm Front arm max reach: 43-3/4" / 1,111 mm Rear arm min reach: 32-1/2" / 825 mm Rear arm max reach: 52-1/2" / 1,333 mm Min pad height: 4" / 102 mm Rise: 69" / 1,753 mm Lift height max (pad only): 73" / 1,854 mm Lift height max (6" adapter): 79" / 2,007 mm Drive-thru clearance: 93" / 2,362 mm Motor: 220 VAC / 60 Hz / 1 Ph Time to full rise: 45 sec Max load per arm: 2,500 lbs. / 1,134 kg Shipping weight: 1,736 lbs. / 789 kg Shipping dimensions: 151" x 18" x 51" / 3,835 mm x 457 mm x 1,295 mm |
*Free shipping is only available in the 48 continental states of the U.S.A. Also note that a fuel surcharge may apply to certain areas.
